8 Inputs 8 Outputs HDMI Matrix Switch 4K60 Video Wall Controller with EDID Management for Large Screen Display

Name: 8 Inputs 8 Outputs HDMI Matrix Switch 4K60 Video Wall Controller with EDID Management for Large Screen Display
Brand: Bitvisus
Price: 1 USD

Buy cheap 8 Inputs 8 Outputs HDMI Matrix Switch 4K60 Video Wall Controller with EDID Management for Large Screen Display product

Brand Name : Bitvisus

Place of Origin : Guangdong, China

MOQ : 1

Price : Contact us

Model Number : BIT-Ma-U1-MC0808

Certification : CE,HDMI,HDCP,RoHS,FCC

Payment Terms : T/T,PayPal

Supply Ability : 1000

Delivery Time : 5-8 days

Packaging Details : 440mm x 200mm x 44.5mm

Material : Metal

HDMI Version : HDMI 2.0

HDCP Version : HDCP 2.2/1.4

Video Bandwidth : 18Gbps

Video Resolution : 4K x 2K@50/60Hz

Color Space : RGB, YCbCr 4:4:4/4:2:2/4:2:0

Color Depth : 8-bit, 10-bit

Dimensions : 440mm x 200mm x 44.5mm

Weight : 4kg

Power Consumption : 43W

Input Voltage : AC 100~240V 50/60Hz

Output Voltage : DC 12V/ 2-3A

Control Interfaces : RS-232, RJ45

Video Scaling : 4K->1080P

Audio Features : Audio Follow-On, Audio Separation

Contact Now

8x8 HDMI Matrix Switch with Video Wall Controller

Professional 4K60 8x8 HDMI Matrix Switcher with 2x2 and 2x3 Video Wall capabilities for large screen display applications.

8 Inputs 8 Outputs HDMI Matrix Switch 4K60 Video Wall Controller with EDID Management for Large Screen Display

Key Features

Ultra HD resolution up to 4Kx2K@60Hz with RGB 4:4:4 color sampling
Advanced matrix switching functionality
Scene save and recall capabilities
Support for Dolby Vision, HDR10+ and HLG
4K to 1080P video scaling on all HDMI output ports
EDID management for optimal compatibility with display devices
Audio Follow-On and Audio Separation features
Multiple control options: front panel buttons, infrared remote, RS-232 and RJ45 host computer

Applications

This modular HDMI Matrix Switcher 8x8 chassis with Video Wall is ideal for conference rooms, radio & television projects, multimedia conference halls, large screen display projects, television teaching, and command control centers.

Technical Specifications

Product Name	4K60 8x8 HDMI Matrix Switcher
Product Features	UHD 4k60, RGB 4:4:4, Matrix switching, EDID function, Scene save/recall, RS232/RJ45 control, push-button, IR remote
HDMI Compatible	HDMI 2.0
HDCP Compatible	HDCP 2.2/1.4
Video Bandwidth	18Gbps
Power Supply	Input: AC 100~240V 50/60Hz Output: DC 12V/ 2-3 A
Resolution / Cable Length	4K@60Hz: 5 meters 4K@30Hz: 10 meters 1080P@60Hz: 15 meters
Power Consumption	43W
Product Size	440mm(L) × 200mm(W) × 44.5mm(H)
Product Weight	4KG
Certification	CE, FCC, ROHS
Support	ODM, OEM
Warranty	1 year
